Material and Plating
Spacing:2.5/2.54mm
Plastic parts;PA66,UL94V-0
Cage:Brass,Tin plating
Screw:M2.0,Steel,Zn Plating
Contact material:Phosphor bronze,Nickel plating
Electrical performance
Rated voltage：300V
Rated current：8A
Ambient temperature:-40℃~+105℃
MAX Soldering:+250℃,5s
Withstanding Voltage:AC2000V/1Min
Contact resistance:20mΩ
Insulation resistance:5000MΩ/1000V
Wire diameter:28-12AWG 2.5mm2
Torque:0.4Nm
Strip length:5-6mm
