Material and Plating
Plastic parts;PA66,UL94V-0
Welding needle:Brass,Tin plating
Screw:M2.5,Steel,zinc Plating
Square box:Brass,Nickel plating
Electrical performance
Rated voltage：300V
Rated current：10A
Contact resistance:20mΩ
Insulation resistance:5000MΩ/1000v
Wire diameter:24-12AWG 2.5mm2
Withstanding Voltage:AC1500V/1Min
Mechanical properties
Ambient temperature:-40℃_~+105℃
MAX Soldering:+250℃,5s
Torque:0.4
Strip length:6-7mm
